CSS610-8P-2S+IN is one of the most well-rounded switches on the market. It is a perfect fit for the most diverse setups: from home networks and small offices to hotels, call centers and so on. The unique combination of size, features, and price offers unbelievable scalability potential.
There are two SFP+ ports for 10 Gigabit fiber connectivity and eight Gigabit Ethernet ports with 802.3af/at and passive PoE-out (you only need a single PSU to provide both).
This switch is all about nice and easy setups. The compact form-factor means easier shipping and handling, while the lightweight SwOS means easier configuration. You can even configure this switch from your web browser! It gives you all the core functionality of a managed switch, and even more: you can manage port-to-port forwarding, broadcast storm control, apply MAC filters, configure VLANs, mirror traffic, apply bandwidth limitations, and even adjust some MAC and IP header fields.
But the real blessing is the combination of SFP+ and PoE-out Ethernet ports. With this setup, you can do all kinds of things on a tight budget. CSS610 has an impressive total PoE-out budget of 140 W, so you can use even in the most intense scenarios – like hotels, conference halls, or call centers! Use the PoE-out ports to connect the IP-phones while the SFP+ ports connect your primary server to the ISP. Or power a bunch of network cameras and instantly upload the footage to the cloud. And manage a cluster of wireless access points at the same time. Also, scalability is no longer a problem. With our pricing, you can afford a switch on every floor!
Like every toolbox needs screwdrivers and pliers, every network can use a solid PoE switch.
CSS610-8P-2S+IN – a solid choice!
Send purchase questions| Details | |
|---|---|
| Product code | CSS610-8P-2S+IN |
| Switch chip model | 88E6193X |
| Dimensions | 272x208x44mm |
| Operating System | SwitchOS Lite |
| Storage size | 64 KB |
| Storage type | FLASH |
| MTBF | Approximately 200'000 hours at 25C |
| Tested ambient temperature | -40°C to 70°C |
| Suggested price | $229.00 |
| Details | |
|---|---|
| Number of AC inputs | 1 |
| AC input range | 100-240 |
| Number of DC inputs | 1 (DC jack) |
| DC jack input Voltage | 48-57 V |
| Max power consumption | 162 W |
| Max power consumption without attachments | 12 W |
| Cooling type | Passive |
| Details | |
|---|---|
| PoE-out ports | Ether1-Ether8 |
| PoE out | 802.3af/at |
| Max out per port output (input 18-30 V) | 1000 mA |
| Max out per port output (input 30-57 V) | 625 mA |
| Total output power | 140 |
| Details | |
|---|---|
| 10/100/1000 Ethernet ports | 8 |
| Number of 1G Ethernet ports with PoE-out | 8 |
| Details | |
|---|---|
| SFP+ ports | 2 |
| Details | |
|---|---|
| CPU temperature monitor | Yes |
| Voltage Monitor | Yes |
| Details | |
|---|---|
| Certification | CE, EAC, ROHS |
| IP | 20 |
| CSS610-8P-2S+IN | |||||||
|---|---|---|---|---|---|---|---|
| Mode | Configuration | 1518 byte | 512 byte | 64 byte | |||
| kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
| Switching | Non blocking Layer 2 throughput | 2,275.7 | 27,635.9 | 6,578.9 | 26,947.4 | 41,666.7 | 21,333.3 |
| Switching | Non blocking Layer 2 capacity | 2,275.7 | 55,271.8 | 6,578.9 | 53,894.7 | 41,666.7 | 42,666.7 |
| Switching | Non blocking Layer 1 throughput | 2,275.7 | 28,000.0 | 6,578.9 | 28,000.0 | 41,666.7 | 28,000.0 |
| Switching | Non blocking Layer 1 capacity | 2,275.7 | 56,000.0 | 6,578.9 | 56,000.0 | 41,666.7 | 56,000.0 |
Download: Full CE declaration (PDF)
Information about CSS610-8P-2S+IN
| [BG] Bulgarian | С настоящето, "Mikrotikls SIA", декларира, че CSS610-8P-2S+IN е в съответствие със съществените изисквания и другитеприложими разпоредби на Директива 2014/30/EC. |
| [CZ] Czech | "Mikrotikls SIA" tímto prohlašuje, že CSS610-8P-2S+IN splňuje základní požadavky a všechna příslušná ustanoveni Směrnice 2014/30/ES. |
| [DK] Danish | Undertegnede "Mikrotikls SIA" erklærer herved, at følgende udstyr CSS610-8P-2S+IN overholder de væsentlige krav og øvrige relevante krav i direktiv 2014/30/EF. |
| [DE] German | Hiermit erklärt "Mikrotikls SIA", dass sich das Gerät CSS610-8P-2S+IN in Übereinstimmung mit den grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie 2014/30/EG befindet. |
| [EE] Estonian | Käesolevaga kinnitab "Mikrotikls SIA" seadme CSS610-8P-2S+IN vastavust direktiivi 2014/30/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakohastele sätetele. |
| [GR] Greek | ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Ο ΚΑΤΑΣΚΕΥΑΣΤΗΣ "Mikrotikls SIA" ΔΗΛΩΝΕΙ ΟΤΙ CSS610-8P-2S+IN ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 2014/30/ΕΚ |
| [EN] English | Hereby, "Mikrotikls SIA", declares that this CSS610-8P-2S+IN is in compliance with the essential requirements and other relevant provisions of Directive 2014/30/EC. |
| [ES] Spanish | Por la presente, "Mikrotikls SIA", declara que este CSS610-8P-2S+IN cumple con los requisitos esenciales y otras exigencias relevantes de la Directiva 2014/30/EC. |
| [IT] Italian | Con la presente "Mikrotikls SIA" dichiara che questo CSS610-8P-2S+IN è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 2014/30/CE. |
| [LV] Latvian | Ar šo "Mikrotikls SIA" deklarē, ka CSS610-8P-2S+IN atbilst Direktīvas 2014/30/EK būtiskajām prasībām un citiem ar to saistītajiem noteikumiem. |
| [LT] Lithuanian | Šiuo "Mikrotikls SIA" deklaruoja, kad šis CSS610-8P-2S+IN atitinka esminius reikalavimus ir kitas 2014/30/EB Direktyvos nuostatas |
| [HU] Hungarian | A "Mikrotikls SIA" ezzennel kijelenti, hogy a CSS610-8P-2S+IN típusú beren-dezés teljesíti az alapvető követelményeket és más 2014/30/EK irányelvben meghatározott vonatkozó rendelkezéseket. |
| [NL] Dutch | Hierbij verklaart "Mikrotikls SIA" dat het toestel l CSS610-8P-2S+IN in overeenstemming is met de essentiële eisen en de andere relevante bepalin-gen van richtlijn 2014/30/EG. |
| [PL] Polish | Niniejszym "Mikrotikls SIA" deklaruje że CSS610-8P-2S+IN jest zgodny z zasadniczymi wymaganiami i innymi właściwymi postanowieniami Dyrektywy 2014/30/EC. |
| [PT] Portuguese | Eu, "Mikrotikls SIA", declaro que o CSS610-8P-2S+IN cumpre os requisitos essenciais e outras provisões relevantes da Directiva 2014/30/EC. |
| [RO] Romanian | Prin prezenta, "Mikrotikls SIA", declară că aparatul CSS610-8P-2S+IN este în conformitate cu cerinţele esenţiale şi cu alte prevederi pertinente ale Directivei 2014/30/CE. |
| [SK] Slovak | "Mikrotikls SIA" týmto vyhlasuje, že CSS610-8P-2S+IN spĺňa základné požiadavky a všetky príslušné ustanovenia Smernice 2014/30/ES. |
| [SI] Slovenian | "Mikrotikls SIA" izjavlja, da je ta CSS610-8P-2S+IN v skladu z bistvenimi zahtevami in drugimi relevantnimi določili direktive 2014/30/ES. |
| [FI] Finish | "Mikrotikls SIA" vakuuttaa täten että CSS610-8P-2S+IN tyyppinen laite on direktiivin 2014/30/EY oleellisten vaatimusten ja sitä koskevien direktiivin muiden ehtojen mukainen. |
| [SE] Swedish | Denna utrustning är i överensstämmelse med de väsentliga kraven och andra relevanta bestämmelser i direktiv 2014/30/EC. |
| [NO] Norwegian | "Mikrotikls SIA", Erklærer herved at CSS610-8P-2S+IN er i samsvar med de grunnleggende krav og øvrige relevante krav i direktiv 2014/30/EF. |
