CRS328-24P-4S+RM is a 28 independent port switch, it has 24 Gigabit Ethernet ports, which offer different power output
options: Passive PoE, low voltage PoE, 802.3af/at (Type 1 “PoE” / Type 2 “PoE+”) with auto-sensing. PoE-Out is passed over mode B pins (4,5+)(7,8-). The four SFP+ ports
provide up to 10 Gbps connectivity options via either optical fiber or Ethernet modules (not included).
CRS328-24P-4S+RM comes in a 1U rackmount case with 100-240 V AC 500 W power supply built-in. The device
consumes up to 44 W leaving guaranteed 450 W (3x150 W per every 8 Ethernet ports) to power your PoE devices. Each
port can provide up to 30 W of power with any power output option you choose.
The device has a “Dual boot” feature that allows you to choose between two operating systems - RouterOS or SwOS. If
you prefer to have a simplified operating system with only switch specific features, use SwOS. If you would like the ability
to use routing and other Layer 3 features in your CRS, use RouterOS. You can select the desired operating system from
RouterOS, from SwOS or from the RouterBOOT loader settings. All the feature set comes with disruptive price, providing
best price/performance on the market.
Send purchase questions
Specifications
| Details |
| Product code |
CRS328-24P-4S+RM |
| Architecture |
ARM 32bit |
| CPU |
98DX3236 |
| CPU core count |
1 |
| CPU nominal frequency |
800 MHz |
| Switch chip model |
98DX3236 |
| Dimensions |
443 x 300 x 44 mm |
| RouterOS license |
5 |
| Operating System |
RouterOS / SwitchOS |
| Size of RAM |
512 MB |
| Storage size |
16 MB |
| Storage type |
FLASH |
| MTBF |
Approximately 200'000 hours at 25C |
| Tested ambient temperature |
-20°C to 60°C |
| Suggested price |
$489.00 |
Powering
| Details |
| Number of AC inputs |
1 |
| AC input range |
100-240 |
| Max power consumption |
494 W |
| Max power consumption without attachments |
44 W |
| Cooling type |
2 fans |
PoE-out
| Details |
| PoE-out ports |
Ether1-Ether24 |
| PoE out |
802.3af/at |
| Max out per port output (input 18-30 V) |
1000 mA |
| Max out per port output (input 30-57 V) |
450 mA |
| Max total out (A) |
20 A |
Ethernet
| Details |
| 10/100/1000 Ethernet ports |
24 |
Fiber
Peripherals
| Details |
| Serial console port |
RJ45 |
Other
| Details |
| CPU temperature monitor |
Yes |
| Current Monitor |
Yes |
| PCB temperature monitor |
Yes |
| Voltage Monitor |
Yes |
| Mode button |
Yes |
Certification & Approvals
| Details |
| Certification |
CE, EAC, ROHS |
| IP |
IP00 |
Included parts
SFP compatibility listOpen
RouterOS software manualOpen
High resolution images
Switching results
Ethernet test results
- All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
- Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
- Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..
